Submersible Borewell pumps are suitable for open wells. Pioneered with advanced engineering practices and state of the art manufacturing process, submersible bore well pumps are best in their class. Unmatched design and top class performance sets them apart while low maintenance issues and energy efficiency, add on to their list of capabilities.
| PUMP TYPE | H.P. RANGE | HEAD RANGE (Mtrs) | DISCHRGE (LPM) |
|---|---|---|---|
| SINGLE PHASE MONOSET | 0.5-5.00 | 12-31 | 40-650 |
| V9 MONO SET | 3.0-20 | 8-55 | 150-2000 |
Salient Features
- Flawless and maintenance free performance even at very low voltage - 180V In Single Phases and 250V In Three Phases.
- No suction trouble
- Saves electricity more by 20% to 30% in comparison to conventionally designed pumps.
- Less maintenance due to safe designs & high precision work.
- Higher discharge due to world class pump design
- Negligible Chances of motor burning due to low current density, efficiency & safely designed motor.
- Pure AISI 304/431 S.S. grade motor shaft and outer shell.
- 100% pure EC Grade copper employed to make winding wire, dual coated with insulation Class-B
- SAND PROOF design of mechanical seal rings and Sand Guards protection.
- Usage: Domestic & Gardening, Industrial & Agricultural
Motor Specification
| Motor Body | Cast Iron/S.S 202 | 50 |
| Stamping | Electrical Grade Silicon Steel Sheet With 3.9 to 4.5 watt loss/hour | |
| Thrust Bearing | S.S. 304 Tilting pad Segment with Carbon Plate. | |
| Bush | G.M. LTB 4 | |
| Rotor Shaft | S.S 410 Grade high Tensile | |
| Seal | Nitrile Rubber oil seal | |
| Winding | poly propylene double coated copper wire | |
| Copper Rotor | Grinding | |
| Balancing | ||
| Burnishing | ||
| IMPELLER | Cast Iron |
